PLD3016 Gantry Mobile CNC Plate Drilling Machine

Product Application Introduction

The machine is mainly used for drilling plate in steel structures such as buildings, bridges and iron towers.

This machine tool can be used for mass continuous production, also can be used for multi variety small batch production.

It can store a large number of processing program, produced plate, next time out can also process the same kind of plate.

1. The machine is mainly composed of bed, gantry, drilling power head, hydraulic system, control system, centralized lubrication system, chip removal system, cooling system, quick change chuck, etc.

2. Hydraulic automatic control stroke power head is our company's patented technology. Before use, it does not need to set any parameters. It can automatically convert fast forward, work forward and fast backward. It is realized through the combined action of electromechanical and hydraulic.

3. The plate is clamped by hydraulic clamp and controlled by foot switch.

4. There are two CNC axes in the machine: gantry movement (x axis); the movement of drilling power head on the gantry beam (Y axis).

5. The machine adopts centralized lubrication system to improve the performance of the machine tool and prolong its service life.

6. The drill bit of the machine tool is cooled by circulating water. There is a chip remover under the bed, which can automatically remove chips.

7. The control program adopts the upper computer programming software developed by our company and matched with PLC. It has the functions of man-machine dialogue, automatic alarm, etc. the plate size can be input by manual keyboard or U disk interface.
