Product Features
* Dual cooling circuit
* Active cooling
* Temperature stability: ±1°C
* Application environment: 0°C ~45°C
* Refrigerant: R32
* User-friendly controller interface
* Integrated alarm functions
* Back mounted fill port and visual water level
* Optimized for high performance at low temperatures
* Ready for immediate use
*Efficiency and Environmental Protection :The dual cooling circuit and active cooling technology ensure stable temperature control with an accuracy of ±1°C. This unit is suitable for use in environments with temperatures ranging from 0°C to 45°C. It utilizes R32 refrigerant, which is environmentally friendly. The controller interface is user-friendly and includes integrated alarm functions to alert users of any deviations from the desired temperature. Additionally, the back-mounted fill port and visible water level make operation easy. This system is optimized for high performance at low temperatures and is ready for immediate use. Overall, it combines high efficiency with strong environmental protection features.
Voltage & Frequency
|
1p 220V/50Hz
|
|
maximum current
|
12.3A
|
|
Rated power
|
2.7kW
|
|
Horsepower
|
1.5hp
|
|
Compressor power
|
0.895kw
|
|
Electric heating power
|
0.9Kw
|
|
Pump power
|
0.37kw
|
|
Fan power
|
0. 1kw
|
|
Maximum air volume of the fan
|
1920m³ ./h
|
|
Rated Flow of the low temperature end
|
16.5-18 L/min
|
|
Rated pressure of the low temperature end
|
3.0bar
|
|
Maximum pressure of low temperature end
|
3.8bar
|
|
Dimensions of the low temperature end interface
|
G1/2-Φ12mm quick connector
|
|
Water temperature setting range of low temperature end
|
21-32℃
|
|
Rated Flow of the high temperature end
|
1.2-1.5 L/min
|
|
Rated pressure of the high temperature end
|
3.0bar
|
|
Dimensions of the high temperature end interface
|
G1/2-Φ10mm quick connector
|
|
Water temperature setting range of high temperature end
|
26-35℃
|
|
Water temperature control accuracy
|
±1℃
|
|
Water Tank
|
13L
|
|
Application environment
|
5-40℃
|
|
Coolant
|
R32
|
|
Noise Level
|
≈64dB(A)
|
|
Net Weight
|
38KG
|
|
Gross weight
|
47KG
|
|
Machine dimension
|
515×470×735mm
|
|
Packing dimension
|
660×510×875mm
|
|
Suitable cooling medium
|
Pure water, glycol
solution(concentration ≤ 30%) |
